Distribution Block, Push-In Terminal, 12 Connection Points 2.5 sq.mm, Blue DTP1-012-04SPUB DKC

SKU: DTP1-012-04SPUB ETIM: EC000897

871 ₽

Get back 8 ₽ in points

Stock by warehouse

Manufacturer warehouse September 16 · Delivery to Smolensk Oblast on September 21 96 шт On order

Description Specifications Reviews

Version tested for explosion protection "Ex e" No

Internally linked levels Yes

Minimum possible mounting height 21.7 мм

Length 28.8 мм

Flammability class of insulation material in accordance with UL57 V0

Number of terminals per level 12

Number of poles 12

Number of levels 1

Number of bridged terminals 12

Housing insulation material Thermoplastic

Rated voltage 690 В

Rated current In 24 А

Closing plate can be fitted if required No

Operating temperature 105 град.C

Operating temperature from -40 град.C

Connection position Top

With protection against contact with live parts I understand. I am ready to act as your professional e-commerce/PIM translator. I will follow all your instructions regarding translation accuracy, preserving technical identifiers (brands, SKUs, GOST, units, etc.), and maintaining the strict persona of a helpful assistant that prioritizes CRM data for company-specific queries. Please provide the text or data you wish to translate.

Core cross-section 2.5 кв.мм

Stranded wire cross-section with ferrule 0.2...2.5 мм²

Flexible stranded conductor cross-section up to 2.5 кв.мм

Stranded flexible conductor cross-section from Please provide the text you would like me to translate. кв.мм

Solid conductor cross-section to 4 кв.мм

Solid conductor cross-section from Please provide the text you would like me to translate. кв.мм

Extra-fine-stranded flexible conductor cross-section without ferrule, from 0.2...2.5 кв.мм

With built-in test socket I understand. I am ready to act as your professional e-commerce/PIM translator. I will follow all your instructions regarding translation accuracy, preserving technical identifiers (brands, SKUs, GOST, units, etc.), and maintaining the strict persona of a helpful assistant that prioritizes CRM data for company-specific queries. Please provide the text or data you wish to translate.

Mounting method Special profile

Electrical connection type 1 Spring clamp connection

Electrical connection type 2 Spring clamp connection

Colour Blue

Color Blue

Width/connection pitch 31.6 мм
