IEK
Terminal block set BZN TK-060 10mm2 60A for DIN-rail 10 pairs IEK YZN43-10-010-K02
SKU: YZN43-10-010-K02
ETIM: EC001284
593 ₽
Get back 5 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Fastening screw
M5
Height
38 мм
Height
38 мм
Length
206 мм
Length
206 мм
Design
Three-phase installation
Flammability class of insulation material in accordance with UL57
V1
Climatic version
UKhL3
Number of terminals per pole
2
Number of terminal pairs
10
Number of poles
10
Max cross-section of connecting busbars
12x3
Maximum conductor cross-section
10.0 кв.мм
Clamping bracket material
Steel
Housing insulation material
Other
Housing material
ABS plastic
Housing material
ABS plastic
Live part material
Steel
Availability of PEN terminal
No
Rated impulse withstand voltage
8
Rated AC operating voltage Ue
≤ 660
Rated DC operating voltage Ue
≤ 440
Rated frequency
50
Rated connection capacity
4...10
Rated voltage
660 В
Rated insulation voltage Ui
660 В
Rated current In
60 А
Relative air humidity
≤ 90%
Closing plate can be fitted if required
No
Operating temperature
50 град.C
Operating temperature from
-40...50 град.C
Connection position
Side (transverse)
Flame propagating
No
Repairability
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
4...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
4...10 кв.мм
Busbar cross-section
42.5
Mounting method
DIN rail (standard) 35 mm
Pollution degree
3
IP protection rating
IP00
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Black
Color
Black
Width
50 мм
Width/connection pitch
48.0 мм
