IEK
Terminal block set BZN TV-1004 10mm2 100A 4 pairs IEK YZN41-04-010-K02
SKU: YZN41-04-010-K02
ETIM: EC001284
324 ₽
Get back 3 ₽ in points
Analogues by specifications
Stock by warehouse
No description available
Fastening screw
M6
Height
34 мм
Height
34 мм
Length
108 мм
Length
108 мм
Design
Three-phase installation
Flammability class of insulation material in accordance with UL57
Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules.
Climatic version
UKhL3
Number of terminals per pole
2
Number of terminal pairs
4
Number of poles
4
Max cross-section of connecting busbars
16x3.5
Maximum conductor cross-section
10.0 кв.мм
Clamping bracket material
Steel
Housing insulation material
Other
Housing material
ABS plastic
Housing material
ABS plastic
Live part material
Steel
Availability of PEN terminal
No
Rated impulse withstand voltage
8
Rated AC operating voltage Ue
≤ 660
Rated DC operating voltage Ue
≤ 440
Rated frequency
50
Rated connection capacity
4...10
Rated voltage
660 В
Rated insulation voltage Ui
660 В
Rated current In
100 А
Relative air humidity
≤ 90%
Closing plate can be fitted if required
No
Operating temperature
50 град.C
Operating temperature from
-40...50 град.C
Connection position
Side (transverse)
Flame propagating
No
Repairability
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
4...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
4...10 кв.мм
Busbar cross-section
34.0
Mounting method
Direct mounting
Pollution degree
3
IP protection rating
IP00
Electrical connection type 1
Bolted connection
Electrical connection type 2
Screw connection
Colour
Black
Color
Black
Width
43 мм
Width/connection pitch
43.0 мм
