Terminal block set BZN TV-2506 2.5mm2 25A 6 pairs IEK YZN41-06-002-K02
SKU: YZN41-06-002-K02
ETIM: EC001284
121 ₽
Price list (incl. VAT):
138 ₽
Available August 25
Order multiple: 50
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
6800 | шт | August 25 | clarifying | |
|
Manufacturer warehouse
Available
|
900 | шт | August 25 | clarifying | |
Select a warehouse to order
Used for safe and compact connection and branching of conductors of various cross-sections made of copper and aluminum in AC circuits with voltage up to 660V and DC circuits with voltage up to 440V.
Installed on a mounting panel. A transparent cover is installed to insulate the conductors.
The enclosure is made of non-flammable ABS plastic. The current-carrying busbar is made of brass.
| Fastening screw | M4 |
| Height | 19 мм |
| Height | 19 мм |
| Length | 91 мм |
| Length | 91 мм |
| Design | Three-phase installation |
| Flammability class of insulation material in accordance with UL57 | Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules. |
| Climatic version | UKhL3 |
| Number of terminals per pole | 2 |
| Number of terminal pairs | 6 |
| Number of poles | 6 |
| Max cross-section of connecting busbars | 9x4 |
| Maximum conductor cross-section | 2.5 кв.мм |
| Clamping bracket material | Steel |
| Housing insulation material | Other |
| Housing material | ABS plastic |
| Housing material | ABS plastic |
| Live part material | Steel |
| Availability of PEN terminal | No |
| Rated impulse withstand voltage | 8 |
| Rated AC operating voltage Ue | ≤ 660 |
| Rated DC operating voltage Ue | ≤ 440 |
| Rated frequency | 50 |
| Rated connection capacity | 1...2.5 |
| Rated voltage | 660 В |
| Rated insulation voltage Ui | 660 В |
| Rated current In | 25 А |
| Relative air humidity | ≤ 90% |
| Closing plate can be fitted if required | No |
| Operating temperature | 50 град.C |
| Operating temperature from | -40...50 град.C |
| Connection position | Side (transverse) |
| Flame propagating | No |
| Repairability | No |
| Flexible stranded conductor cross-section up to | 2.5 кв.мм |
| Stranded flexible conductor cross-section from | 1...2.5 кв.мм |
| Solid conductor cross-section to | 2.5 кв.мм |
| Solid conductor cross-section from | 1...2.5 кв.мм |
| Busbar cross-section | 9.5 |
| Mounting method | Direct mounting |
| Pollution degree | 3 |
| IP protection rating | IP00 |
| Electrical connection type 1 | Bolted connection |
| Electrical connection type 2 | Screw connection |
| Colour | Black |
| Color | Black |
| Width | 30 мм |
| Width/connection pitch | 30.0 мм |
