EMAS
Inductive sensor (NPN-NO) M12x3 connector (sensing distance 5mm 800Hz) flush mounting 10-30V DC IP67 EMAS SIM18FM1NSX
SKU: SIM18FM1NSX
ETIM: EC002714
5,405 ₽
Get back 54 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Sensor height
73 мм
Sensor diameter
18 мм
Switching output design
NPN/NO
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of safe semiconductor outputs
0
Number of safe semiconductor outputs with signaling function
0
Number of safety outputs with contact
0
Number of safe outputs with signalling function contact
0
Housing construction
Threaded cylinder
Maximum output current at protected output
200 мА
Housing material
Metal
Mechanical installation requirement for sensor
Flush
Supply voltage to
30 В
Supply voltage from
10 В
Suitable for security systems
Yes
Housing coating
Chrome plating
Immunity to magnetic fields
Resistance to DC and AC magnetic fields
Operating distance
5 мм
Current type
Direct current (DC)
Cascadable
No
With monitoring function for connected devices
No
Actuation method
Magnetic
Connection type
Flat plug connector
Resistance to load
Yes
Switching frequency
800 Гц
Sensor width
24 мм
