EMAS
Magnetic sensor (1NC+1NO) wire 2m (operating dist. 5mm) left output IP68 EMAS SMB10LC2-B15
SKU: SMB10LC2-B15
ETIM: EC002544
10,471 ₽
Get back 104 ₽ in points
Analogues by specifications
No description available
Cross/short circuit detection possible
Yes
Sensor height
88 мм
Guaranteed operating switching distance
5 мм
Guaranteed operating shutoff distance
5 мм
Sensor diameter
0 мм
Sensor length
88 мм
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of safe semiconductor outputs
0
Number of safety outputs with contact
0
Housing construction
Cuboid
Maximum output current at protected output
0 мА
Housing material
Plastic
Minimum output current
0 мА
Rated AC mains supply voltage 50 Hz to
0 В
Rated AC 50 Hz mains supply voltage from
50 В
Rated DC supply voltage to
0 В
Rated DC supply voltage from
0 В
Housing coating
Varnished
With status indication
No
Actuation method
Magnetic
IP protection rating
IP68
Operating temperature to
70 град.C
Operating temperature from
-25 град.C
Connection type
Cable
Sensor width
50 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
