IEK
Strap holder bar/rod 25-40mm/6-8mm galv. steel IEK ZDP51-11-1-68-40
SKU: ZDP51-11-1-68-40
ETIM: EC000508
553 ₽
Get back 5 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Double bridge support holder for strip/rod is designed for surface mounting of a conductor, as well as for connecting round and flat conductors. Conductor axis rotation is possible. Fixed to the surface using fasteners. Conductor connection is made via a bolted connection. Housing material - steel with galvanic zinc coating.
Weight
0.26 кг
Height
57 мм
Length
75 мм
Holder material
Zinc/Galvanized steel
Holder material
Hot-dip galvanized steel
Clamp material
Steel
Bottom material
Hot-dip galvanized steel
Tightening torque from
20.5...23.5 Н·м
Suitable for round conductors with diameter at
8 мм
Suitable for round conductors with diameter from
6 мм
Conductor dimensions
Other
Operating temperature from
-60...40 град.C
Holder mounting type
Cover plate with hole
Conductor fastening type
With screw clamp
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
