Screw Cable Jack DK-5V 67093 KVT

• Screw jack is designed to lift cable drums and hold them aloft for unwinding • The jack shaft is made of solid metal rod and equipped with clamping shoes to prevent drum movement along the shaft during cable unwinding • The jack construction is made of steel equal-leg angle 50x50x5 mm • Maximum allowable drum weight: 5 t • Drum sizes: from No. 8 to No. 22 • Delivery set: • Two vertical welded stands with base • Shaft Ø 48 mm length 1700 mm • Two clamping shoes • Two screw rods • Two nuts for adjusting lifting height • Two handle extensions for adjustment nuts • Screw rods have a trapezoidal thread resistant to loads • Overall stand dimensions (LxWxH): 1450x700x1300 mm • Total jack weight: 114 kg
