IEK
Additional Input Terminal for CTS Terminal Block 70/120mm2 grey IEK YCT10-00-K03-070-AUX
SKU: YCT10-00-K03-070-AUX
ETIM: EC000897
302 ₽
Get back 3 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Length
53.60 мм
Number of terminals per level
1
Number of poles
1
Number of levels
1
Housing insulation material
Other
Housing material
Polyamide 6.6
Housing material
Polyamide 6.6
Rated voltage
1000 В
Rated current In
41.0 А
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
0.5...6 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
0.5...10 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.5...6 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey
Color
Grey
Width/connection pitch
8.0 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
780 ₽
DKC Distribution block, push-in terminal, 18 connection points 2.5 mm², red DTP1-018-04SPUR DKC
SKU: DTP1-018-04SPUR
595 ₽
DKC Distribution Block, push-in clamp, 1 input 6 sq.mm, 12 connection points 2.5 sq.mm, red DTP1-112-104SPUR DKC
