ESCA 3 Vertical internal bend 90deg 50x100-0,6 IEK ES3-PN-90-050-100-06
SKU: ES3-PN-90-050-100-06
ETIM: EC002400
512 ₽
Get back 5 ₽ in points
Analogues by specifications
Stock by warehouse
Vertical internal 90° turn is designed for organizing the cable route turn in the vertical plane.
The accessory is supplied flat, featuring guide perforations for bending and assembly of the product before installation.
The connection of the accessory to the tray is made via a telescopic connector. Suitable for all types of ESCA series sheet trays. The cover for the accessory is ordered separately.
The accessory is made of steel galvanized by the Sendzimir method (zinc coating layer no less than 5-10 μm).
Weight
0.22 кг
Material type/grade
Other
Height
50 мм
Height
50 мм
Cable tray height
50 мм
Length
168 мм
Length
168 мм
Protective surface coating
Sendzimir galvanizing
Direction change
Vertically ascending (internal)
Design
Integrated connector
Corrosion resistance class
2
Climatic version
U2, HL2, UHL2, OM2
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
90
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
0.6
Zinc coating thickness
10
Colour
Light grey
Color
Light grey
Width
100 мм
Cable tray width
100 мм
Branch width
100 мм
Wide-range version
No
