IEK
90 degree external vertical tray angle 150x35 steel 0.8mm ESCA 5 IEK ES5-PV-90-035-150-08
SKU: ES5-PV-90-035-150-08
ETIM: EC002400
920 ₽
Get back 9 ₽ in points
Analogues by specifications
Vertical external bend 90° is designed for routing cable trays in a vertical plane.
The accessory is joined to the tray using a telescopic connector. Suitable for all types of ESCA series sheet metal trays. The cover for the accessory is ordered separately.
The accessory is made of galvanized steel using the Sendzimir method (zinc protective layer is at least 5-10 μm).
Weight
0.27 кг
Material type/grade
Other
Height
35 мм
Height
35 мм
Cable tray height
35 мм
Length
209 мм
Length
209 мм
Protective surface coating
Sendzimir galvanizing
Direction change
Vertically descending (external)
Design
Integrated connector
Corrosion resistance class
2
Climatic version
U2, HL2, UHL2, OM2
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
90
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
0.8
Zinc coating thickness
10
Colour
Light grey
Color
Light grey
Width
150 мм
Cable tray width
150 мм
Branch width
150 мм
Wide-range version
No
