IEK
Vertical internal tray angle 45deg. 80x400 1.2mm HDZ ESCA 5 IEK ES5-PN-45-080-400-12-HDZ
SKU: ES5-PN-45-080-400-12-HDZ
ETIM: EC002400
5,303 ₽
Analogues by specifications
Vertical internal turn of 45° is designed to organize the turning of the cable route in the vertical plane.
The connection of the accessory to the tray is carried out via a telescopic connector.
Suitable for all types of ESCA series sheet metal trays.
The cover for the accessory is ordered separately.
The accessory is made of hot-dip galvanized steel (zinc protective layer not less than 55 μm).
Weight
1.39 кг
Material type/grade
Other
Height
80 мм
Height
80 мм
Cable tray height
80 мм
Length
245 мм
Length
245 мм
Protective surface coating
Hot-dip coating
Direction change
Vertically ascending (internal)
Design
Integrated connector
Corrosion resistance class
6
Climatic version
U1, KhL1, UKhL1, UKhL5, OM1
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
45
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
1.2
Zinc coating thickness
55
Colour
Light grey
Color
Light grey
Width
400 мм
Cable tray width
400 мм
Branch width
400 мм
Wide-range version
No
