ESCA 7 Vertical external bend 90deg 80x300-1,5 IEK ES7-PV-90-080-300-15
SKU: ES7-PV-90-080-300-15
ETIM: EC002400
4,208 ₽
Analogues by specifications
The 90° external vertical bend is designed for organizing cable route turns in the vertical plane.
The accessory is joined to the tray using a telescopic connector.
Suitable for all types of ESCA series sheet cable trays.
The cover for the accessory is ordered separately.
The accessory is made of galvanized steel using the Sendzimir method (zinc coating layer of at least 5-10 μm).
Weight
1.15 кг
Material type/grade
Other
Height
80 мм
Height
80 мм
Cable tray height
80 мм
Length
272 мм
Length
272 мм
Protective surface coating
Sendzimir galvanizing
Direction change
Vertically descending (external)
Design
Integrated connector
Corrosion resistance class
2
Climatic version
U2, HL2, UHL2, OM2
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
90
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
1.5
Zinc coating thickness
10
Color
Light grey
Colour
Light grey
Width
300 мм
Cable tray width
300 мм
Branch width
300 мм
Wide-range version
No
