IEK
Vertical tray corner internal 45deg 80x200 2mm RAL 9016 ESCA 7 IEK ES7-PN-45-080-200-20-RGA
SKU: ES7-PN-45-080-200-20-RGA
ETIM: EC002400
8,764 ₽
Get back 87 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
45° internal vertical bend is designed for organizing cable route turns in a vertical plane.
Connection of the accessory to the tray is made via a telescopic connector.
Suitable for all types of ESCA series sheet trays.
The cover for the accessory is ordered separately.
Accessory is made of Sendzimir galvanized steel (zinc coating thickness not less than 5-10 μm).
Weight
1.75 кг
Material type/grade
Other
Height
80 мм
Height
80 мм
Cable tray height
80 мм
Length
316 мм
Length
316 мм
Protective surface coating
Powder coating
Direction change
Vertically ascending (internal)
Design
Integrated connector
Corrosion resistance class
2
Climatic version
U2, HL2, UHL2, OM2
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
9016
Perforated side wall
No
Rotation (angle)
45
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
2.0
Zinc coating thickness
10
Colour
Pure white
Color
Pure white
Width
200 мм
Cable tray width
200 мм
Branch width
200 мм
Wide-range version
No
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
