2,891 ₽
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
GIF sleeves for messenger neutral wires serve for mechanical and electrical connection of phase wires in SIP systems with a messenger neutral. Applicable for aluminum multi-strand wires; a specific wire cross-section corresponds to a specific color of the sealing ring. The internal cavity of the aluminum part is filled with contact grease, which protects the aluminum surface from oxidation and reduces contact resistance, leading to a significant reduction in energy losses. The insulation material is a polymer resistant to ultraviolet radiation and climatic conditions. For messenger wires, the allowable mechanical loads on the crimped connection are 60% of the strength of the messenger neutral.
Weight
0.05 кг
Outer diameter
22.0 мм
Internal diameter 1
8.0
Inner diameter 2
8.0
Operating temperature range
-50...+60
Length
98.0 мм
Length
98.0 мм
For strain-relieved connections
Yes
Material
Aluminum
Nominal cross-section of aluminum cores
35 кв.мм
Suitable for aluminium-magnesium cables
No
Application
For main phase conductors
Voltage range
Up to 1 kV
Left-side SIP cross-section
35.0
Right-side SIP cross-section
35.0
Die type for sleeve crimping
E173
Reduced rated cross-section - aluminum
Please provide the text you would like me to translate. мм²
Cross-section shape
Stranded round/sector conductor
Left sealing ring color
Red
Right sealing ring colour
Red
