GRILDOT FLD (100x100) 20W 2M 940 WH (89x89x40) 1749001050 Svetovye Tekhnologii
SKU: 1749001050
ETIM: EC002892
5,653 ₽
Get back 56 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Compact LED luminaires for installation in GRILLATO ceilings made using FLD technology. The presence of 2M, 3M, 4M, or 6M in the designation indicates the number of modules in the luminaire. Since the diffuser and the visible part of the housing effectively merge into a "single whole", the luminaire is supplied only in white color.
Without dimming
Yes
Supplied with lamp
Yes
Outer diameter
0 mm
Built-in length
89 mm
Built-in height/depth
65 mm
Height/depth
65 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
GPRS dimming
No
LineSwitch dimming
No
RF dimming
No
Zigbee dimming
No
Dimming depending on control mechanism
No
Voltage modulation dimming
No
Push-button dimming
No
Trailing-edge phase dimming
No
Leading-edge phase-cut dimming
No
Length
99 mm
Colour rendering index
90-100 (class 1A)
Grille design
White
Electric shock protection class
II
Built-in luminaire energy efficiency class
A++, A+, A (LED)
Power factor
0.9
Maximum power
20 W
Housing material
Steel
Diffuser/lampshade material
Polymethyl methacrylate (PMMA)
Mounting diameter
0 mm
Rated voltage from
230...230 V
Rated luminous flux
1800 lm
Rated current from
87...87 mA
Ballast included
Yes
Suitable for ceiling fastening
No
Suitable for lamp power from
20...20 W
Suitable for wall mounting
No
Suitable for continuous light lines
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for number of light sources
1
Suitable for emergency lighting
No
Dimming potentiometer (built-in)
No
Designed for flush mounting
Yes
Programmable dimming
No
Fire protection "d"
No
Light distributor
No (without)
DSI dimming
No
Current type
DC (direct)
With motion sensor
No
With light sensor
No
With protective grille/mesh/screen
No
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
0.75 mm²
Sinusoidal dimming
No
Manufacturer's proprietary dimming system
No
Special application
Housing and utilities
IP protection rating
IP40
Ambient temperature from
5...35 °C
Lamp type
LED non-replaceable
Light beam angle
Very wide light beam >80 deg
Impact resistance
IK02
Control device
LED driver (LED power supply)
Housing color
White
Light color
White
Colour temperature from
4000...4000 K
Lamp base (holder)
No (without)
Width
99 mm
Installation width
89 mm
Luminaire efficiency
90 lm/W
