Световые Технологии
INSEL LB/S LED G3 70W D130 757 WH SB 1334003660 Svetovye Tekhnologii
SKU: 1334003660
ETIM: EC002892
Price on request
Analogues by specifications
No description available
Without dimming
Yes
Supplied with lamp
Yes
Outer diameter
0 mm
Built-in length
0 mm
Built-in height/depth
0 mm
Height/depth
169 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
GPRS dimming
No
LineSwitch dimming
No
RF dimming
No
Zigbee dimming
No
Voltage modulation dimming
No
Push-button dimming
No
Trailing-edge phase dimming
No
Leading-edge phase-cut dimming
No
Length
331 mm
Colour rendering index
70-79 (class 2A)
Colour category
Cool daylight (>5300 K)
Electric shock protection class
I
Fire hazard class
P-I,II,IIa,III
Built-in luminaire energy efficiency class
Other
Number of LEDs
1
Power factor
0.96
Maximum power
76 W
Housing material
Aluminum
Reflector material
Other
Mounting diameter
0 mm
Rated voltage from
230...230 V
Rated luminous flux
12400 lm
Reflector
Other
Ballast included
Yes
Suitable for lamp power from
76...76 W
Suitable for number of light sources
1
Suitable for emergency lighting
No
Dimming potentiometer (built-in)
No
Programmable dimming
No
Fire protection "d"
No
Light distributor
No (without)
DSI dimming
No
Current type
AC/DC
With protective cover
Yes
With protective cover
Yes
With protective grille/mesh/screen
No
Luminous flux
12400...12400 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
2.5 mm²
Sinusoidal dimming
No
Manufacturer's proprietary dimming system
No
Special application
No (without)
Mounting method
Other
Average rated service life
100 000 h
IP protection rating
IP66
Ambient temperature from
-40...60 °C
Lamp type
LED non-replaceable
Light beam distribution angle
130 °
Light beam angle
Very wide light beam >80 deg
Impact resistance
IK08
Control device
LED driver (LED power supply)
Housing color
White
Light color
White
Light colour per EN 12464-1
Cool daylight >5300 K
Colour temperature from
5700...5700 K
Lamp base (holder)
No (without)
Width
331 mm
Installation width
0 mm
