Rexant
Power supply 110-220V AC/12V DC 9A 100W with DC connector 5.5x2.1 without moisture protection IP23 Rexant 200-100-3
SKU: 200-100-3
ETIM: EC002540
Price on request
Analogues by specifications
The power supply (AC adapter) is used to ensure high-quality operation of lighting fixtures. It is used to power LED devices, security and video surveillance systems, as well as any other low-voltage systems.
IP43 rating provides protection of the enclosure against the ingress of large dust particles and water splashes, allowing the unit to be used outdoors, for example, in a garden or on a terrace.
This model has a power of 100 W and is equipped with a 5.5x2.1 mm DC connector for connection.
Overall dimensions (LxWxH): 170x65x38 mm.
Wall mounting possible
No
Busbar mounting possible
No
Height
40 мм
Output power
108 Вт
Output voltage 1 at
12 В
Output voltage 1 from
12 В
Depth
137 мм
Short-circuit protection
Yes
Maximum output current 1
9 А
Modular design
No
Rated AC mains supply voltage 50 Hz to
250 В
Rated AC 50 Hz mains supply voltage from
110 В
Rated DC supply voltage to
12 В
Rated DC supply voltage from
12 В
Power consumption
97 Вт
Adjustable output voltage
No
Supply voltage current type
Direct current (DC)
Stabilized
No
IP protection rating
IP43
Controlled regulated output voltage
No
Width
58 мм
