ITK (группа IEK)
ITK 1U Optical distribution patch panel equipped with: SC (Simplex) 16pcs, (OM4) FOBX24-1U-16SCUS04
SKU: FOBX24-1U-16SCUS04
ETIM: EC001130
2,921,112 ₽
Get back 29,211 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 174 шт
Analogues by specifications
Stock by warehouse
Optical distribution frames are designed for switching optical signals either from backbone communication lines or for distributing these signals to small server and office optical networks. They can be wall-mounted or 19” versions.
Weight
2.700 кг
Screw ST3 9x9_5
16
Height
40.0 мм
Height
40.0 мм
Height in conventional units
1
M4 nut
2
Depth
212.0 мм
KDZS
16
Optical fibre class
OM4
Number of ports
16
Bracket
2
Splice cassette cover
1
Marking labels for pigtails, set
1
Material
Steel
RAL colour number
7035
Optical pigtail MM 50/125 OM4 SC/UPC LSZH 1.5m
16
Panel for 8 optical adapters SC or LC Duplex
2
Tie bar
3
SC-SC Simplex MM UPC through-adapter
16
With number of couplings/adapters
16
With pigtail
Yes
Splice cassette for 32 KDZS sleeves
1
Mounting method
Rack-mount
IP protection rating
IP22
External connector type
SC
Impact resistance
IK07
Panel retainer
6
Cable clamp
2
Color
Grey
Colour
Grey
Width
405.0 мм
