ITK (группа IEK)

SKU: RC1-RS485-01-F-3307

ETIM: EC003249

19821 ₽

Price list (incl. VAT): 19821 ₽

Preorder

Order multiple: 60 шт

Description Specifications Reviews

Armoured	No
Cable outer diameter	≤ 14.7
Wave impedance	100 Ом
Conductor diameter	0.64 мм
Cable length	200 м
For laying in the ground	No
Permissible operating temperature (no movement) to	70 град.C
Permissible operating temperature (without movement) from	-50...70 град.C
Protective sheath	No
Core insulation	Compounded rubber
Category	Other
Conductor class	Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6	ng(A)-FRLS
Number of cores	2
Number of twisted elements	1
Max DC resistance per 100m at 20°C, not more than	≤ 6.06
Cable/wire grade	RS-485 port
Core marking	Colour
Outer sheath material	PVC
Conductor material	Copper
Mounting temperature from	-10...50 град.C
Outer diameter (approx.)	14.7 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)	Yes
Rated voltage from	≤ 300 В
Rated conductor cross-section	0.35 кв.мм
With metal cable	No
Halogen-free (per IEC 60754-2)	No
Operating temperature from	-50...70 град.C
Twist type	Lay (layer)
UV resistance	No
Outer sheath colour	Orange
Signal frequency	≤ 1
Screen over the twist	Foil + braid
Screen over stranding element	Foil
Twisting element	Paired
