ITK (группа IEK)
ITK Interface cable fire-resistant RS-485 1x2x0.80 ng(A)-FRLS orange (200m) RC1-RS485-01-F-5307
SKU: RC1-RS485-01-F-5307
ETIM: EC003249
1,582,086 ₽
Get back 15,820 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 66 м
Analogues by specifications
Fire-resistant single-pair interface cable is intended for digital communication systems, security systems, and fire protection systems. It is approved for use in systems employing the RS-485 and Profibus standards. It maintains functionality in fire conditions for 180 minutes. Designed for group indoor and outdoor installation with protection against precipitation and solar radiation, with low smoke and gas emission.
Armoured
No
Cable outer diameter
≤ 14.7
Wave impedance
100 Ом
Conductor diameter
0.80 мм
Cable length
200 м
For laying in the ground
No
Permissible operating temperature (no movement) to
70 град.C
Permissible operating temperature (without movement) from
-50...70 град.C
Protective sheath
No
Core insulation
Compounded rubber
Category
Other
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRLS
Number of cores
2
Number of twisted elements
1
Max DC resistance per 100m at 20°C, not more than
≤ 3.83
Cable/wire grade
RS-485 port
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
14.7 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage from
≤ 300 В
Rated conductor cross-section
0.50 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Operating temperature from
-50...70 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Signal frequency
≤ 1
Screen over the twist
Foil + braid
Screen over stranding element
Foil
Twisting element
Paired
