ITK (группа IEK)
ITK Twisted pair F/UTP cat. 5E 4x2x0.52 PVCLSng(A)-FRLS orange (305m) LC1-C5E04-357
SKU: LC1-C5E04-357
ETIM: EC003249
26,936,990 ₽
Get back 269,369 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 305 м
Analogues by specifications
Stock by warehouse
Fire-resistant symmetrical cable is intended for digital communication systems, IP-SOUE, operating via Ethernet protocol. 4-pair F/UTP cable, category 5e. Maintains functionality in fire conditions for 180 minutes. Designed for group internal routing with low smoke and gas emission.
Armoured
No
Cable outer diameter
5.5
Wave impedance
100 Ом
Conductor diameter
0.52 мм
Cable length
305 м
For laying in the ground
No
Permissible operating temperature (no movement) to
70 град.C
Permissible operating temperature (without movement) from
-50...70 град.C
Protective sheath
No
NVP value
69 %
Core insulation
Compounded rubber
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRLS
Number of cores
8
Number of twisted elements
4
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
≤ 9.5
Cable/wire grade
F/UTP
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
5.5 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated transmission rate
69
Rated voltage from
≤ 145 В
Rated conductor cross-section
0.18 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Core cross-section
24 мм
Insulation resistance
500
Operating temperature from
-50...70 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Signal frequency
100
Screen over the twist
Foil
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
