ITK (группа IEK)
ITK twisted pair F/UTP cat.5E 4x2x0.52 ZHng(A)-FRHF orange (305m) LC1-C5E04-367
SKU: LC1-C5E04-367
ETIM: EC003249
28,283,565 ₽
Get back 282,835 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 305 м
Analogues by specifications
Stock by warehouse
Fire-resistant symmetrical cable is designed for digital communication systems and IP-Voice Evacuation systems operating via Ethernet protocol. 4-pair F/UTP cable, Category 5e. Maintains functionality in fire conditions for 180 minutes. Designed for group indoor installation. The sheath is made of halogen-free compound.
Armoured
No
Cable outer diameter
5.5
Wave impedance
100 Ом
Conductor diameter
0.52 мм
Cable length
305 м
For laying in the ground
No
Permissible operating temperature (no movement) to
90 град.C
Permissible operating temperature (without movement) from
-70...90 град.C
Protective sheath
No
NVP value
69 %
Core insulation
Compounded rubber
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRHF
Number of cores
8
Number of twisted elements
4
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
≤ 9.5
Cable/wire grade
F/UTP
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
5.5 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated transmission rate
69
Rated voltage from
≤ 145 В
Rated conductor cross-section
0.18 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
Yes
Core cross-section
24 мм
Insulation resistance
500
Operating temperature from
-70...90 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Signal frequency
100
Screen over the twist
Foil
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
