ITK (группа IEK)
ITK twisted pair U/UTP cat.5E 4x2x24AWG solid PVC gray (305m) RF LC1-C5E04-111-S-R
SKU: LC1-C5E04-111-S-R
ETIM: EC003249
1,072,140 ₽
Get back 10,721 ₽ in points
Order multiple: 48 шт
Analogues by specifications
Stock by warehouse
No description available
Cable outer diameter
5.2
Wave impedance
100±15 Ом
Conductor diameter
0.51 мм
Cable length
305 м
For laying in the ground
No
Permissible operating temperature (without movement) from
-40...60 град.C
NVP value
69 %
Core insulation
Solid polyethylene
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
O1.8.2.5.4
Number of cores
8
Number of twisted elements
4
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
9.5
Cable/wire grade
U/UTP
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
5.2 мм
Rated transmission rate
69
Rated voltage from
75 В
Rated conductor cross-section
0.20 кв.мм
With metal cable
No
Core cross-section
24 мм
Insulation resistance
5000
Operating temperature from
-40...60 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Grey
Signal frequency
100
Screen over the twist
No
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
