425 ₽
Get back 4 ₽ in points
Analogues by specifications
Stock by warehouse
IEK stepped insulators are designed for rigid mounting and insulation of busbars inside electrical cabinets, busbar bridges, and other equipment.
The insulators can be used in DC and AC electrical equipment with a frequency of 50 Hz and a voltage up to 1000 V, and guarantee the absence of breakdown between busbars.
The insulator housing is made of a special, impact-resistant, non-flammable polymer with high electrical resistance properties.
Weight
170 кг
Material type/grade
Glass-fibre reinforced polyamide
Lightning impulse withstand voltage
7.5
Height
105.0 мм
Height
105.0 мм
Depth
18.0 мм
Hole diameter for fastening bolts in busbars
6.6
Thread length
10 мм
Number of poles
5
Short-time power-frequency withstand voltage
2.5
Maximum design current
530 А
Material
Polymer material
Busbar spacing
20.5...30 мм
Metric thread size
6; 5
Tightening torque of busbar fastening bolts
5.0
Power-frequency insulation breakdown voltage
6.0
Rated voltage
660 В
Bus pack 5(3), 10(2)
No
Flexural strength
125
Breaking torque
25
Operating temperature from
-60...80 град.C
Design type
Stepped insulator
Busbar thickness
Please provide the text you would like me to translate. мм
Color
Red
Colour
Red
Width
135.0 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
