ITK (группа IEK)
ITK Armored Cable RS-485 1x2x0.80 Kng(A)-FRLS orange (200m) FR1-01-F-5327
SKU: FR1-01-F-5327
ETIM: EC003249
373 ₽
Get back 3 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Armoured
No
Cable outer diameter
≤ 6.5
Wave impedance
100 Ом
Conductor diameter
0.80 мм
Cable length
200 м
For laying in the ground
No
Permissible operating temperature (no movement) to
70 град.C
Permissible operating temperature (without movement) from
-50...70 град.C
Protective sheath
Other
Core insulation
Compounded rubber
Category
Other
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRLS
Number of cores
2
Number of twisted elements
1
Max DC resistance per 100m at 20°C, not more than
≤ 3.83
Cable/wire grade
RS-485 port
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
6.5 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage from
≤ 300 В
Rated conductor cross-section
0.50 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Insulation resistance
10
Operating temperature from
-50...70 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Signal frequency
≤ 1
Screen over the twist
Foil + braid
Screen over stranding element
Foil
Twisting element
Paired
