223 ₽
Get back 2 ₽ in points
Analogues by specifications
"BUS CAN – data transmission cables for CAN (Controller Area Network) systems complying with ISO 11898,
with a nominal characteristic impedance of 120 Ohm.
Cables are designed for signal control and transmission for computing devices, electronic
control and monitoring devices, for applications where shielded small-section cables with optimal protection against electrical interference are required.
UV-resistant.
Designed for use in dry and wet rooms.
Cables are designed for highly flexible applications, in towed cable chains, constantly
moving machines and mechanisms.
Construction
Based on standards: ISO11898 and EU-Directive 2011/65/EU.
Flexible strands made of non-tinned copper wires, 19x0.185 ± 0.01 mm.
Strand insulation made of foamed polyethylene.
Strand identification: color coding in accordance with DIN 47100.
Insulated strand twisting: paired.
Non-woven tape winding over the twisted pairs.
Shield in the form of a braid of tinned copper wires (coverage density 85%).
Sheath: polyurethane, color purple (RAL 4001), outer cable diameter 8.1 ± 0.3 mm."
Permissible operating temperature (no movement) to
80 град.C
Permissible operating temperature (without movement) from
-30 град.C
Protective grounding conductor
No
Core insulation
Polyethylene (PE)
Conductor class
5 - flexible stranded
Number of cores
2
Core marking
Colour
Oil resistance in accordance with EN 60811-2-1
No
Outer sheath material
Polyvinyl chloride (PVC)
Outer diameter (approx.)
7500 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated voltage U
250 кВ
Rated conductor cross-section
It appears your message contains only ".5". Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. кв.мм
Fire resistance
In accordance with EN 60332-1-2
Recommended installation temperature during pulling, up to
60 град.C
Recommended installation temperature during pulling from
-30 град.C
Low temperature resistance in accordance with EN 60811-1-4
No
Outer sheath colour
Purple
