132 ₽
Get back 1 ₽ in points
Analogues by specifications
"BUS LD – data transmission cables for BUS systems based on RS485/RS422 interface, such as Modbus, SUCOnet P, Modulink P, VariNet-P.
Cables are designed for signal transmission for computing devices, industrial automation, and applications where small cross-section shielded cables with maximum protection against electrical interference are required.
Intended for use in dry and wet rooms.
Cables are designed for stationary and limited movement installation.
LD – data transmission over long distances.
Construction
•
Flexible strands made of non-tinned copper wires, 7x0.2 ± 0.01 mm.
•
Insulation of strands made of polyethylene.
•
Strand identification: color coding in accordance with DIN 47100.
•
Twisting of insulated strands: twisted pair.
•
PET film winding over the twisted pairs.
•
Shield in the form of a braid of tinned copper wires (coverage density 85%).
•
Sheath: PVC compound, color violet (RAL 4001), outer cable diameter 7.1 ± 0.3 mm."
Permissible operating temperature (no movement) to
80 град.C
Permissible operating temperature (without movement) from
-30 град.C
Protective grounding conductor
No
Core insulation
Polyethylene (PE)
Conductor class
5 - flexible stranded
Number of cores
2
Core marking
Colour
Oil resistance in accordance with EN 60811-2-1
No
Outer sheath material
Polyvinyl chloride (PVC)
Outer diameter (approx.)
5700 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated voltage U
250 кВ
Rated conductor cross-section
.22 кв.мм
Fire resistance
In accordance with EN 60332-1-2
Recommended installation temperature during pulling, up to
60 град.C
Recommended installation temperature during pulling from
-30 град.C
Low temperature resistance in accordance with EN 60811-1-4
No
Outer sheath colour
Purple
