Price on request
Analogues by specifications
FLEX-H Halogen-free fire-resistant power cable with improved fire safety characteristics. This cable is suitable for fixed or flexible installation, intended for use as a power or connection cable, and meets the strictest fire safety requirements; installation is carried out in dry and wet rooms, and is also suitable for limited outdoor use.
- low fire load
- low smoke emission (low smoke or LS)
- reduced flame spread
- Oil resistance: IEC / EN 60811-404 IRM 902 4 h 70 °C ± 8
Permissible operating temperature (no movement) to
80 град.C
Permissible operating temperature (without movement) from
-40 град.C
Protective grounding conductor
Yes
Core insulation
Halogen-free polymer compound
Conductor class
5 - flexible stranded
Number of cores
4
Core marking
Digits
Oil resistance in accordance with EN 60811-2-1
Yes
Outer sheath material
Halogen-free polymer compound
Outer diameter (approx.)
9.8 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage U
300 кВ
Rated conductor cross-section
2.5 кв.мм
Fire resistance
In accordance with EN 60332-3-22
Recommended installation temperature during pulling, up to
70 град.C
Recommended installation temperature during pulling from
-15 град.C
Low temperature resistance in accordance with EN 60811-1-4
No
Outer sheath colour
Grey
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
