Flexicore (LAPP)

FLEXICORE 100 нг(А)-LS 0.6/1kV 4G50 (m) LAPP 3120000900

SKU: 3120000900 ETIM: EC000057

Price on request

Description Specifications Reviews

Armoured No

Permissible operating temperature (no movement) to 80 град.C

Permissible operating temperature (without movement) from -50 град.C

Protective grounding conductor Yes

Core insulation Polyvinyl chloride (PVC)

Conductor class 5 - flexible stranded

Number of cores 4

Maximum permissible conductor temperature 80 град.C

Cable/wire grade FLEXICORE 100

Core marking Colour

Outer sheath material Polyvinyl chloride (PVC)

Conductor material Copper

Display present No

Outer diameter (approx.) 33.5 мм

Low smoke emission in accordance with EN 61034-2 (ng-LS version) Yes

Rated voltage U .6 кВ

Rated conductor cross-section 50 кв.мм

Fire resistance In accordance with IEC 60332-3-22

Recommended installation temperature during pulling, up to 80 град.C

Recommended installation temperature during pulling from -15 град.C

Lead sheath No

Conductor strand shape Round

Outer sheath colour Black
