H07RN–F RU is a flexible power and control cable with rubber insulation and rubber sheath of Russian production, based on international standard 50525-2-21 with improved characteristics. For connecting mobile machines, mechanisms, and equipment to electrical networks at a rated voltage of 450/750 V AC with a rated frequency of up to 400 Hz or a rated DC voltage of 1000 V. The cable is designed for operation under conditions of exposure of the sheath to disinfectants, aggressive substances, as well as lubricating oils. Continuous long-term immersion in water to a depth of up to 100 m (only standing water, temperature not less than +5°C, non-potable).
Armoured
No
Permissible operating temperature (no movement) to
85 град.C
Permissible operating temperature (without movement) from
-50 град.C
Protective grounding conductor
Yes
Core insulation
Rubber (EPR)
Conductor class
5 - flexible stranded
Number of cores
3
Maximum permissible conductor temperature
80 град.C
Cable/wire grade
H07RN-F
Core marking
Colour
Outer sheath material
Rubber (EPR)
Conductor material
Copper
Display present
No
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated voltage U
.45 кВ
Rated conductor cross-section
70 кв.мм
Fire resistance
In accordance with IEC 60332-1-2
Recommended installation temperature during pulling, up to
60 град.C
Recommended installation temperature during pulling from
-40 град.C
Lead sheath
No
Conductor strand shape
Round
Outer sheath colour
Black
