ITK (группа IEK)
ITK Interface cable fire-resistant RS-485 2x2x0.80 нг(А)-FRHF orange (200m) RC1-RS485-02-F-5407
SKU: RC1-RS485-02-F-5407
ETIM: EC003249
10,357,700 ₽
Get back 103,577 ₽ in points
Order multiple: 200 м
Analogues by specifications
No description available
Armoured
No
Cable outer diameter
≤ 14.7
Wave impedance
100 Ом
Conductor diameter
0.80 мм
Cable length
200 м
For laying in the ground
No
Permissible operating temperature (no movement) to
90 град.C
Permissible operating temperature (without movement) from
-70...90 град.C
Protective sheath
No
Core insulation
Organosilicon rubber (silicone)
Category
Other
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRHF
Number of cores
4
Number of twisted elements
2
Max DC resistance per 100m at 20°C, not more than
≤ 3.83
Cable/wire grade
RS-485 port
Core marking
Colour
Outer sheath material
Other
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
14.7 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated voltage from
≤ 300 В
Rated conductor cross-section
0.50 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
Yes
Operating temperature from
-70...90 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Signal frequency
≤ 1
Screen over the twist
Foil + braid
Screen over stranding element
Foil
Twisting element
Paired
