KPSng(A)-FRHF 1x2x1.50 mm2 cable is a fire-resistant symmetrical twisted pair cable that does not propagate fire during group installation and has low smoke and gas emission. It maintains operability in fire conditions for 180 minutes. Manufactured according to TU 27.32.13-002-39644825-2020.
Used in the organization of fire protection systems, smoke protection systems, fire alarm systems (FAS), evacuation management and warning systems (EMWS), as well as in the organization of automatic fire extinguishing systems (AFES).
The cable is used in all critical life support systems that must remain operational in fire conditions.
The cable consists of a single-wire copper conductor, insulation made of fire-resistant ceramizing organosilicon rubber, a copper drain wire, and a halogen-free PVC jacket. Thanks to 100% annealing of the copper cores, the cable becomes softer, which simplifies the installation process and increases service life.
The use of the KPSng(A)-FRHF cable is regulated by the Customs Union Certificate of Conformity (EAC).
Cable marking: KPSng(A)-FRHF Nx2xS, where N is the number of pairs and S is the cross-section of the current-carrying conductors.
Armoured
No
Conductor diameter
1.38 мм
For laying in the ground
No
Permissible operating temperature (no movement) to
70 град.C
Permissible operating temperature (without movement) from
-40 град.C
Core insulation
Rubber
Insulation per GOST R IEC 60331
Yes
Category
No (without)
Conductor class
1 - single-wire
Number of cores
2
Number of twisted elements
1
Cable/wire grade
KPSng(A)-FRHF
Core marking
Digits
Oil-resistant
No
Oil-resistant (in accordance with IEC 60811-404)
No
Outer sheath material
Polyvinyl chloride (PVC)
Conductor material
Copper
Outer diameter (approx.)
7.8 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated conductor cross-section
1.5 кв.мм
Fire resistance
In accordance with IEC 60332-3-22
Main insulation
Rubber (silicone)
Longitudinal water blocking
No
Radial water blocking
No
Recommended installation temperature during pulling, up to
60 град.C
Recommended installation temperature during pulling from
-10 град.C
With low smoke emission in accordance with IEC 61034-2
Yes
Halogen-free (per EN 60754-1/2)
Yes
Halogen-free (per IEC 60754-2)
Yes
Twist type
Bundled
UV resistance
No
Outer sheath colour
Orange
Screen over the twist
No (without)
Screen over stranding element
No (without)
Twisting element
Paired
