Price on request
Analogues by specifications
Cable with tin-plated copper conductors, with insulation and sheath made of non-flammable polyvinyl chloride plastic according to category (A) when laid in a bundle, with low smoke and gas emission, (E-shielded). Cables are designed for operation in a stationary state at an ambient temperature from -50 °C to +50 °C and relative air humidity up to 98% at temperatures up to 35 °C
Permissible operating temperature (no movement) to
50 град.C
Permissible operating temperature (without movement) from
-50 град.C
Core insulation
Polyvinyl chloride (PVC)
Conductor class
3 - stranded
Number of cores
6
Core marking
Colour
Oil resistance in accordance with EN 60811-2-1
No
Outer sheath material
Polyvinyl chloride (PVC)
Outer diameter (approx.)
10 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage U
500 кВ
Rated conductor cross-section
.75 кв.мм
Fire resistance
No
Recommended installation temperature during pulling, up to
50 град.C
Recommended installation temperature during pulling from
-15 град.C
Low temperature resistance in accordance with EN 60811-1-4
Yes
Outer sheath colour
Black
