ITK (группа IEK)
ITK Fire-resistant cable КПСнг(А)-FRLSLTх 2х2х1,5 red (200m) FR1-02-U-8504
SKU: FR1-02-U-8504
ETIM: EC003249
12,757,644 ₽
Get back 127,576 ₽ in points
Order multiple: 200 м
Analogues by specifications
No description available
Armoured
No
Cable outer diameter
≤ 8.6
Conductor diameter
1.38 мм
Cable length
200 м
For laying in the ground
No
Permissible operating temperature (no movement) to
70 град.C
Permissible operating temperature (without movement) from
-50...70 град.C
Protective sheath
No
Core insulation
Compounded rubber
Category
Other
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
ng(A)-FRLSLTx
Number of cores
4
Number of twisted elements
2
Max DC resistance per 100m at 20°C, not more than
≤ 11.28
Cable/wire grade
KPSng(A)-FRLS
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
8.6 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage from
≤ 300 В
Rated conductor cross-section
1.5 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Insulation resistance
10
Operating temperature from
-50...70 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Orange
Screen over the twist
No
Screen over stranding element
No
Twisting element
Paired
