ITK (группа IEK)
ITK Twisted pair U/UTP cat.5E 2x2x24AWG solid PVC 1m grey (100m/coil) LC1-C5E02-111-100
SKU: LC1-C5E02-111-100
ETIM: EC003249
57 ₽
Get back 1% in points
Analogues by specifications
No description available
Cable outer diameter
4.2±0.2
Wave impedance
100 Ом
Conductor diameter
0.51 мм
Cable length
100 м
For laying in the ground
No
Permissible operating temperature (no movement) to
60 град.C
Permissible operating temperature (without movement) from
-40...60 град.C
NVP value
69 %
Core insulation
Solid polyethylene
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
O1.8.2.5.4
Number of cores
4
Number of twisted elements
2
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
9.5
Cable/wire grade
U/UTP
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated transmission rate
69
Rated voltage from
≤ 48 В
Rated conductor cross-section
0.20 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Core cross-section
24 мм
Insulation resistance
5000
Operating temperature from
-40...60 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Grey
Signal frequency
100
Screen over the twist
No
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
