АЛЬФАКАБЕЛЬ
Cable VVG-Png(A) 2x1.5 OK (N) 0.66kV (coil 20m) (pc) ALFAKABEL 45993
SKU: 45993
ETIM: EC000057
1,404 ₽
Get back 14 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
• PURPOSE
Cables are designed for the transmission and distribution of electricity in stationary electrical installations at a nominal AC voltage of 0.66; 1, 3 kV with a nominal frequency of 50 Hz. (P) means flat. ng-non-flammable (A) - Category by fire safety performance
• FIELD OF APPLICATION
Used in residential, office, and industrial premises.
• PRINCIPLE OF OPERATION
The principle of operation of the cable is based on the transmission of electricity through current-carrying conductors.
• ADDITIONAL ACCESSORIES OR ACCESSORIES
The standard kit includes the product itself
Armoured
No
Permissible operating temperature (no movement) to
50 град.C
Permissible operating temperature (without movement) from
-50 град.C
Protective grounding conductor
No
Core insulation
Polyvinyl chloride (PVC)
Conductor class
1 - single-wire
Number of cores
2
Maximum permissible conductor temperature
70 град.C
Cable/wire grade
VVG-Png(A)
Core marking
Colour
Outer sheath material
Polyvinyl chloride (PVC)
Conductor material
Copper
Display present
No
Outer diameter (approx.)
7.2 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated voltage U
.66 кВ
Rated conductor cross-section
1.5 кв.мм
Fire resistance
No
Recommended installation temperature during pulling, up to
50 град.C
Recommended installation temperature during pulling from
-15 град.C
Lead sheath
No
Conductor strand shape
Round
Outer sheath colour
Black
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
