• PURPOSE
VVGng(A)-LS cables are designed for the transmission and distribution of electricity in stationary electrical installations at a nominal alternating voltage of 0.66; 1.3 kV with a nominal frequency of 50 Hz. (A)-fire safety category; LS—low smoke and gas emission (Low Smoke).
• APPLICATION AREA
Used in residential, office, and industrial premises.
• PRINCIPLE OF OPERATION
The principle of operation of the cable is based on the transmission of electricity through current-carrying conductors. The cable insulation is made of non-combustible materials.
Armoured
No
Permissible operating temperature (no movement) to
50 град.C
Permissible operating temperature (without movement) from
-50 град.C
Protective grounding conductor
Yes
Core insulation
Polyvinyl chloride (PVC)
Conductor class
2 - stranded
Number of cores
4
Maximum permissible conductor temperature
70 град.C
Cable/wire grade
VVGng(A)-LS
Core marking
Colour
Outer sheath material
Polyvinyl chloride (PVC)
Conductor material
Copper wire
Display present
No
Outer diameter (approx.)
26 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated voltage U
1 кВ
Rated conductor cross-section
35 кв.мм
Fire resistance
No
Recommended installation temperature during pulling, up to
-15 град.C
Recommended installation temperature during pulling from
-15 град.C
Lead sheath
No
Conductor strand shape
Round
Outer sheath colour
Black
