1,395 ₽
Get back 13 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
From our own stock you can buy 56 шт in any quantity. Above that — supply on order, in multiples of 6 шт.
Analogues by specifications
Stock by warehouse
AVDT32 residual current circuit breakers are designed to protect people from electric shock in case of insulation failure in electrical installations, to prevent fires due to leakage currents to ground, and to protect against overload and short circuits.
Recommended for protecting group lines supplying outdoor sockets, sockets, and lighting in basements and garages.
Mounting installation depth
71 мм
Number of protected poles
1
Number of poles
2
Maximum supply cable cross-section
25 кв.мм
Availability of residual current release
Yes
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
4
Rated differential making and breaking capacity
6000
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated voltage
230 В
Rated current
25 А
Rated leakage current
0.03 мА
Total number of poles
2
Breaking capacity
6.0 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
20
IP protection rating
IP20
Residual current type
A
Connection type
Screw connection
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
2
