IEK
KARAT RCBO AVDT32EM 1P+N B10 30mA type A IEK KA-VD14-1-010-B-030-A
SKU: KA-VD14-1-010-B-030-A
ETIM: EC000905
3,015 ₽
Get back 30 ₽ in points
Analogues by specifications
Stock by warehouse
Used in AC networks in private and multi-apartment buildings.
Designed to protect outgoing lines from short-circuit and overload currents, as well as to protect people from electric shock. They do not have electronic components, meaning they are not dependent on network voltage. This is particularly important during a neutral wire break.
Overvoltage protection
No
Protection class per GOST IEC 61140
0
Number of protected poles
1
Number of poles
1P+N
Maximum supply cable cross-section
25 кв.мм
Mechanical durability
20000
Rated differential making and breaking capacity
3000
Rated breaking capacity per IEC 60947-2
6 кА
Rated voltage
230 В
Rated current
10 А
Rated leakage current
0.03 мА
Total number of poles
2
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
IP protection rating
IP20
Operating temperature
-25...45
Residual current type
Please provide the text you would like me to translate.
Connection type
Screw connection
Tripping characteristic
Please provide the text you would like me to translate.
Width in modular units
2
Electrical wear resistance
10000
