IEK

KARAT Circuit breaker VA47-60M 4P B 16A 6kA IEK MVA31-4-016-B

SKU: MVA31-4-016-B

ETIM: EC000042

1102 ₽

Price list (incl. VAT): 1764 ₽

Available August 17

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Склад производителя Available	220	шт	August 17	August 17

Select a warehouse to order

Description Specifications Reviews

Weight per pole	≤ 0,2
Additional equipment possible
Busbar connection capability	PIN (pin), FORK (fork)
Release response time in short-circuit range tm	0,1
Mounting installation depth	71 мм
Electric shock protection class	0
Current limiting class
Climatic version	UKhL4
Number of protected poles	4
Number of poles
Number of power poles	4
Maximum supply cable cross-section	25 кв.мм
Mech. endurance	≥ 20000
Explosion protection present	Without explosion protection
Availability of residual current release	No
Thermal release available	Yes
Electromagnetic release present	Yes
Electronic release available	No
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V	6 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V	6 кА
Rated breaking capacity in accordance with EN 60898	кА
Rated voltage	400 В
Rated current	16 А
Total number of poles	4
Power loss	14.0 Вт
Current type	AC/DC
Tripping system	Thermal, electromagnetic
Mounting method	On DIN rail
IP protection rating	IP20
Application area	Industrial and domestic
Mounting rail type	35x7.5
Connection type
Tripping characteristic	B
Frequency	50 Гц
Frequency at	50 Гц
Frequency from	50 Гц
Width in modular units	4
Electrical endurance	≥ 8000
