KARAT Circuit breaker VA47-60M 4P B 5A 6kA IEK MVA31-4-005-B
SKU: MVA31-4-005-B
ETIM: EC000042
1773 ₽
Price list (incl. VAT):
2838 ₽
Preorder
Order multiple: 3
VA47-60M switches perform the functions of automatic disconnection of the electrical installation in case of overcurrent and operational control of sections of electrical circuits.
These devices are perfectly suited for use in group panels (apartment and floor), as well as in metering and distribution boards of administrative and residential buildings.
| Weight per pole | ≤ 0.2 |
| Additional equipment possible | Yes |
| Busbar connection capability | PIN (pin), FORK (fork) |
| Release response time in short-circuit range tm | 0.1 |
| Mounting installation depth | 71 мм |
| Electric shock protection class | 0 |
| Current limiting class | 3 |
| Climatic version | UKhL4 |
| Number of protected poles | 4 |
| Number of poles | 4 |
| Number of power poles | 4 |
| Maximum supply cable cross-section | 25 кв.мм |
| Mech. endurance | ≥ 20000 |
| Explosion protection present | Without explosion protection |
| Availability of residual current release | No |
| Thermal release available | Yes |
| Electromagnetic release present | Yes |
| Electronic release available | No |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 6.0 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 6.0 кА |
| Rated breaking capacity in accordance with EN 60898 | 6 кА |
| Rated voltage | 400 В |
| Rated current | 5.0 А |
| Total number of poles | 4 |
| Power loss | 12.0 Вт |
| Current type | AC/DC |
| Tripping system | Thermal, electromagnetic |
| Mounting method | On DIN rail |
| IP protection rating | IP20 |
| Application area | Industrial and domestic |
| Mounting rail type | 35x7.5 |
| Connection type | Screw connection |
| Tripping characteristic | Please provide the text you would like me to translate. |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 4 |
| Electrical endurance | ≥ 8000 |
