IEK
KARAT Residual Current Circuit Breaker AD12 2P 25A 10mA type AC IEK MAD10-2-025-C-010
SKU: MAD10-2-025-C-010
ETIM: EC000905
1,202 ₽
Get back 12 ₽ in points
Analogues by specifications
Stock by warehouse
Fast-acting protective switches provide:
in the version with trip settings of 10 and 30 mA:
- protection of people from electric shock during direct unintentional contact with live parts of electrical equipment;
in the version with trip settings of 100 and 300 mA:
– protection against fire due to ignition of insulation of live parts;
– protection against overload and short circuit;
– protection against unacceptable network voltage increases (AD12M).
The products provide indication of tripping due to differential current, and for the AD12M, there is also LED indication of the ON state. The AD12M maintains functionality when the electrical network voltage is reduced to 110 V.
Automatic circuit breakers of the new VA47-29 series are used as switching devices in the products.
Mounting installation depth
72.1 мм
Number of protected poles
2
Number of poles
2
Maximum supply cable cross-section
35 кв.мм
Availability of residual current release
Yes
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
4
Rated differential making and breaking capacity
4500
Rated breaking capacity in accordance with EN 60898
4.5 кА
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated voltage
230 В
Rated current
25 А
Rated leakage current
0.01 мА
Total number of poles
2
Breaking capacity
4.5 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
20
IP protection rating
IP20
Residual current type
Alternating current (AC)
Connection type
Screw connection
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
3
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1835 ₽
CHINT Residual current circuit breaker 2P (1P+N) D 20A 100mA type AC 6kA AVDT NXBLE-63YH D20 electron. (R) CHINT 515335
SKU: 515335
1698 ₽
CHINT Residual current circuit breaker 2p D 16A 300mA type AC 6kA NXBLE-63 (R) CHINT 982571
SKU: 982571
1334 ₽
DEKraft Residual current circuit breaker 2p C 25A 30mA type AC 4.5kA DIF-101 4.5mod. DEKraft 15005DEK
SKU: 15005DEK
1787 ₽
DKC Compact RCBO YON maks (YON max) type MDR, 1P+N, 30mA, 32A, curve C, 6kA, type A MDR32N-1N2C32-A DKC
