IEK
KARAT Residual Current Circuit Breaker AD12S 2P 32A 100mA type AC IEK MAD13-2-032-C-100
SKU: MAD13-2-032-C-100
ETIM: EC000905
1,372 ₽
Get back 13 ₽ in points
Analogues by specifications
Selective differential circuit breakers AD12S with built-in overcurrent protection are designed for constructing multi-stage (selective) differential current protection circuits.
AD12S differential circuit breakers provide:
- protection against electric shock upon direct unintentional contact with live parts of electrical equipment;
- protection against insulation combustion of live parts in the event of a leakage current;
- protection against overload and short circuit.
The devices feature indication of differential current tripping.
New series VA47-29 circuit breakers are used as switching devices.
Number of protected poles
2
Number of poles
2
Maximum supply cable cross-section
35 кв.мм
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
4
Rated differential making and breaking capacity
4500
Rated breaking capacity in accordance with EN 60898
4.5 кА
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated voltage
230 В
Rated current
32 А
Rated leakage current
0.1 мА
Total number of poles
2
Breaking capacity
4.5 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
IP protection rating
IP20
Residual current type
Alternating current (AC)
Connection type
Screw connection
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
3
