DKC
Double-level terminal block, screw clamp, 4 connection points, 4 mm², gray TTURB-4 DKC
SKU: TTURB-4
ETIM: EC000897
213 ₽
Get back 2 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Two-level terminal block with screw connection designed for connecting four conductors. DIN-rail OMEGA mounting. Operating temperature from -40 to +105°C. Housing made of PA 6.6 with UL-94 V0 flammability rating.
Gray color, 4 connection points, 4 mm2. 2 channels for plug-in jumpers on each level. Dimensions (H×W×D) 66×73.5×6.2 mm.
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
66 мм
Length
73.5 мм
Length
73.5 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
4
Number of levels
2
Housing insulation material
Thermoplastic
Rated voltage
500 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
Core cross-section
4 кв.мм
Stranded wire cross-section with ferrule
0.25...4 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
.2 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.2 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...6 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey
Color
Grey
Width/connection pitch
6.2 мм
