DKC
Double-Level Terminal, push-in clamp, 4 connection points, 4 sq.mm, grey VPRTT-4-GY DKC
SKU: VPRTT-4-GY
ETIM: EC000897
246 ₽
Get back 2 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Two-level Push-in terminal block is designed for connecting four conductors, and a push-button provides protection against installation errors and accidental contact. Mounting is on an OMEGA DIN rail. Operating temperature from -40 to +105°C. Housing is made of PA 6.6 with flammability class V0 UL-94. Grey color, 4 connection points, 4 mm2. Plug-in jumpers. Dimensions (H×W×D) 47.6×83.7×6.2 mm.
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
47.6 мм
Length
83.7 мм
Length
83.7 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
4
Number of levels
2
Housing insulation material
Thermoplastic
Rated voltage
500 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Top
Core cross-section
4 кв.мм
Stranded wire cross-section with ferrule
0.2...4 мм²
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
.14 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.2 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.14...4 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Grey
Color
Grey
Width/connection pitch
6.2 мм
