Two-level terminal, push-in clamp, 4 connection points, 4 sq.mm, blue VPRTT-4-BU DKC
SKU: VPRTT-4-BU
ETIM: EC000897
435 ₽
Get back 4 ₽ in points
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
47.6 мм
Length
83.7 мм
Length
83.7 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
4
Number of levels
2
Housing insulation material
Thermoplastic
Rated voltage
500 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Top
Core cross-section
4 кв.мм
Stranded wire cross-section with ferrule
0.2...4 мм²
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
Please provide the text you would like me to translate. You only provided ".14", which does not contain meaningful text for translation. кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
Please provide the text you would like me to translate. кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.14...4 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Blue
Color
Blue
Width/connection pitch
6.2 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
2588 ₽
DKC Distribution block, screw clamp, flat 24x8 mm, 2x35 mm2, 5x16 mm2, 4x10 mm2 POD-500 DKC
SKU: POD-500
75 ₽
КЭАЗ Mini spring-loaded feed-through terminal block OptiClip CXM-2.5-I-BU-24A-(0.2-2.5) blue KÉAZ 331822
SKU: 331822
540 ₽
DKC Two-level terminal block, screw clamp, 4 connection points, 4 mm², grey KRUK-5-PV DKC
SKU: KRUK-5-PV
131 ₽
IEK ARMAFIX Spring terminal CX6-3 6mm2 three-contact gray IEK AF-CT40-00-3-K03-006
