Measuring terminal, screw clamp, 2 connection points, 6 sq.mm, gray TUR-6-RTK-S DKC
SKU: TUR-6-RTK-S
ETIM: EC000902
447 ₽
Get back 4 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Screw clamp measuring terminal is designed for connecting two conductors and connecting current and voltage measuring transformers. It has a built-in longitudinal movable jumper and the possibility of installing a short-circuit jumper between terminals to short-circuit the secondary circuits of current transformers. Mounting on OMEGA DIN-rail. Operating temperature from -40 to +105°C. The housing is made of PA 6.6 with flammability class V0 UL-94.
Gray color, 2 connection points, 6 mm2. Screw and sliding jumper system. Dimensions (H×W×D) 51.5×72×8.2 mm.
Internally linked levels
false
Minimum possible mounting height
51.5 мм
Length
72 мм
Length
72 мм
Cross blade design
Sliding
Longitudinal blade design
Sliding
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
57 А
Closing plate can be fitted if required
false
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
Stranded wire cross-section with ferrule
0.5...6 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
.5 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
.5 кв.мм
Cross-section of extra-fine-stranded flexible conductor without ferrule to
6 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
.5 кв.мм
With built-in test socket
Yes
Mounting method
DIN rail/G-rail
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey
Color
Grey
Width/connection pitch
8.2 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
185 ₽
Klemsan Spring terminal block with DIN-rail connector 2.5mm2 ser. PCY 2.5 Klemsan 364019
SKU: 364019
487 ₽
Phoenix Contact Terminal block with knife disconnectors ST 2.5-TWIN-MT Phoenix Contact 3036356
SKU: 3036356
904 ₽
КЭАЗ 2-level push-in terminal block OptiClip CPDLK-2.5-2L-MT-N-I-S ser. КЭАЗ 331874
