Rexant
Ceramic screw terminal 16mm2 2 pairs of contacts with mounting hole (pack 50pcs) Rexant 07-6224
SKU: 07-6224
ETIM: EC001284
283,650 ₽
Get back 2,836 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
REXANT heat-resistant terminal blocks are designed for connecting wires that may be exposed to high temperatures. Made of high-quality insulating material that has high dielectric strength even when exposed to moisture, is resistant to surface leakage currents, and is non-flammable.
1. Multi-strand wire cross-section - 16mm2
2. Rated current - 30A
3. Rated operating voltage - 400V
4. Connection type - screw
5. Number of terminals 2x2
6. Operating temperature range: from -40 to +450 0C.
Version tested for explosion protection "Ex e"
No
Number of terminals per pole
2
Number of poles
2
Housing insulation material
Ceramic
Rated voltage
400 В
Rated current In
30 А
Operating temperature
450 град.C
Operating temperature from
-40 град.C
Connection position
Side
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
6 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
White
