DKC
Feed-through terminal, bolt clamp, 2 connection points, 35 mm², grey FER-35 DKC
SKU: FER-35
ETIM: EC000897
1,394 ₽
Get back 13 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Feed-through terminal block with bolt clamp is designed for switching 2 conductors. Mounting on OMEGA DIN rail or panel. Operating temperature from -40 to +105°C. Housing is made of PA 6.6 with flammability class V0 UL-94.
Grey color, 2 connection points, 35 mm2. Mounting of jumpers on the terminal stud. Dimensions (H×W×D) 54.5×107×27 mm.
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
54.5 мм
Length
107 мм
Length
107 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
125 А
Closing plate can be fitted if required
No
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
Core cross-section
35 кв.мм
Stranded wire cross-section with ferrule
2.5...50 мм²
Mounting method
DIN rail 35 mm
Electrical connection type 1
Bolted connection
Electrical connection type 2
Bolt connection
Colour
Grey
Color
Grey
Width/connection pitch
27 мм
